The Effect of Hot and Cold EGR Applications on Exhaust Emissions in Diesel Engines
Abstract views: 4
/
PDF downloads: 2
Keywords:
EGR, NOx, Smoke, HC, CO EmissionsAbstract
In this study, the effects of hot and cold Exhaust Gas Recirculation (EGR) applications on
exhaust emissions in diesel engines were experimentally investigated. Tests were conducted by applying
both hot and cold EGR at 10% and 20% rates, and the resulting emission values were compared with
standard operating conditions. The results revealed that both types of EGR significantly reduced NOx
emissions. However, as the EGR rate increased, notable increases were observed in HC, CO, and smoke
emissions. These increases are attributed to the reduction in oxygen concentration and combustion
temperature in the combustion chamber caused by EGR, which negatively affects combustion efficiency.
In particular, the further decrease in combustion temperature with cold EGR applications exacerbated
these negative effects. In conclusion, although EGR applications are effective in controlling NOx
emissions, they must be carefully optimized due to their adverse impact on other harmful emissions. The
findings suggest that to balance engine emissions effectively, EGR rate, application type (hot/cold), and
engine operating parameters must be evaluated together.
Downloads
References
Borken, J., & Dubé, D., Diesel Engine Emissions and Emission Control, Environmental Engineering Science, 34(9), 573-581, 2017.
Sjoberg, M., & Jonsson, A., Reduction of Diesel Engine Emissions with Advanced Technologies., Journal of Automobile Engineering, 15(4), 65-79, 2019.
Lapuerta, M., & Armas, O., Fuel Injection and Emission Control Systems in Diesel Engines., Energy Conversion and Management, 122, 106-118, 2016.
Hwang, J., & Lee, J., nfluence of Exhaust Gas Recirculation on NOx Emissions in Diesel Engines, Energy Conversion and Management, 170, 200-210, 2018.
Gaitonde, A., & Ramesh, A., The Role of Exhaust Gas Recirculation in Diesel Engine Emission Control., Journal of Engine Research, 12(3), 157-169, 2017.
Khan, M. S., & Kim, Y., Modeling and Simulation of EGR in Diesel Engines for NOx Reduction, Fuel, 263, 116779,2020.
Zhao, H., & Li, X., Impact of Exhaust Gas Recirculation on Diesel Engine Performance and Emissions, Fuel Science and Technology, 10(4), 45-58, 2019.
Hira, J., Sharma, R., Kamboj, K., Kumar, V., & Sharma, P., NOx Emission Reduction in Diesel Engine Through Developed Cooled EGR Setup, Advances in Interdisciplinary Engineering, 1–13, 2019.
Guan, W., Pedrozo, V., Zhao, H., Ban, Z., & Lin, T., Exploring the NOx Reduction Potential of Miller Cycle and EGR on a HD Diesel Engine Operating at Full Load, SAE Technical Paper 2018-01-0243,,2018.
Schwoerer, J., Dodi, S., Fox, M., Huang, S., & Yang, Z. , Internal EGR Systems for NOx Emission Reduction in Heavy-Duty Diesel Engines, SAE Technical Paper 2004-01-1315,2004.
Shivashimpi, M. M., Alur, S. A., & Banapurmath, N. R., Exhaust Gas Recirculation as a NOx Reduction Technique for Modified POME Fuelled Diesel Engine, International Journal of Vehicle Structures and Systems, 14(2), 1926,2022.
Park, Y., Shiyu, L., Zhang, X., Liu, Y., & Tan, Y., Experimental Study on NOx Reduction of Diesel Engine by EGR Coupled with SCR." PMC. https://www.ncbi.nlm.nih.gov/pmc/articles/PMC10882660/, 2023.
López, J., García, J., & Martínez, M., Effects of Cooled Exhaust Gas Recirculation on NOx and PM Emissions in a Diesel Engine." Energy and Fuels, 34(6), 7583-7595.,2020.
Shao, W., Lin, H., & Zhang, Y., Impact of Exhaust Gas Recirculation on NOx and CO2 Emissions in Diesel Engines, Journal of Engineering Science and Technology, 16(8), 5618-5634, 2021.
Yang, L., Zhang, M., & Xie, H., Effect of Exhaust Gas Recirculation on Diesel Engine Emissions under High Load, Energy Conversion and Management, 149, 168-176, 2017.
Lapuerta, M., & Armas, O., Influence of Exhaust Gas Recirculation on Diesel Engine Emissions and Performance., Energy Conversion and Management, 122, 106-118, 2016.
Dündar, G., Arslan, M., & Çolak, İ., Effect of Exhaust Gas Recirculation on Emission Characteristics in Diesel Engines Under Low Temperature and Load Conditions., Energy Reports, 8, 579-589, 2022.
Kim, S., Park, J., & Lee, J., Effects of Exhaust Gas Recirculation on Performance and Emissions of Diesel Engines with Cooled EGR System, Applied Thermal Engineering, 174, 115326, 2020.
Singh, R., Sharma, N., & Singh, R., Effect of Exhaust Gas Recirculation on Diesel Engine Emissions under Different Load Conditions, International Journal of Energy and Environmental Engineering, 10(1), 53-60, 2019.
